BEAM 230L

Model: SI-220L BEAM 230L

The BEAM 230L is a stylish moving head beam in a very compact and lightweight housing. It delivers high light output and even coverage field. It features a 230W Lamp. The lamp equips with the reflector built-in, providing perfect lamp alignment. The moving head features ultra sharp beam effect with low consumption. The fixture is integrated with a full complement of professional characteristics including a static gobo wheel, color wheel, 8+16-Facet prism, frost filter, motorized linear focus, variable speed shutter/strobe, linear dimmer, color time and gobo time controllable. The fixture supports DMX, RDM (Remote Device Management).

The fixture’s exterior housing is beautifully balanced basing on a modern design philosophy with supremely harmonious interior structure for remarkable control. The sculpted body of the BEAM 230L achieves more than just a striking look. The 2*1/4 turn fastening omega clamps, available for vertical and horizontal plug-in, make installations fast and easy.

It’s applicable for large scale live concerts, TV productions, road shows, clubs, etc.

Light Source
Source: 230W lamp
Color Temperature: 8000K
12000lm (source), 6600lm(fixture)
CRI: ≥85
Flicker free operation for broadcast TV and FILM
Life Span: 2000H
The life span may vary depending on several following factors but not limited to：
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, etc.
Optics
A set of high resolution and precise optics
Anti-reflection 116mm front lens
2.5°Beam angle
Smooth and linear electric focus
Movement
PAN movement: 540°(8/16 bit）
PAN movement: 270°(8/16 bit）
Fast, quiet, smooth and precise 2-Phase motors
Smooth, fast and precise resolution for PAN/TILT movement with low noise operation
Scan position memory, auto reposition after unexpected movement
Gobo System
1 Static gobo wheel with 16 gobos plus open
Gobo time controllable
