• PROFILE 300H/200H/600H-IP PROFILE 300H/200H/600H-IP

Model: SI-298 PROFILE 300H/200H/600H-IP

Today more and more stage lights are being exposed to wet, humid and extreme conditions. With numerous multi-environmental application requirements, Color Imagination recently launched an high power IP65 rated LED profile lights (Ellipsoidal).

These PROFILEs are a series of high definition and noise free LED studio lights integrated into a die-cast aluminum alloy housing. It features the brightest output and the boldest rendering of the colors. The fixture is a professional SPOT lighting system integrated an electronic framing system (with iris) with an smooth motorized zoom system (15°-30°).

The PROFILEs are equiped with a very versatile dimming system with 4 preset dimming curves. The frequency could be adjusted between 500Hz and 25000Hz. The CRI is ≥90. It’s controllable by DMX512 or RDM.

The PROFILEs are ideal for outdoor shows/installations, museums, retail outlets, restaurants, light labs, children's theaters, and other small scale installations where size matters.

  • Light Source
  • Source:
  • SI-298A PROFILE 300H-IP: 300W 5-IN-1 LED (RGBAL)
  • SI-298B PROFILE 300HWW-IP: CITIZEN 300W WW 3200K LED
  • SI-298C PROFILE 300HCW-IP: CITIZEN 300W CW 5600K LED
  • SI-298D PROFILE 200HWW-IP: CITIZEN 200W WW 3200K LED
  • SI-298E PROFILE 200HCW-IP: CITIZEN 200W CW 5600K LED
  • SI-298F PROFILE 600HD-IP: 600W 2-IN-1 LED, 3200K-5600K
  • CRI: ≥95
  • Flicker free operation for broadcast TV and FILM
  • Frequency adjustable between 500Hz and 25000Hz
  • Life Span: 50000H
  • The life span may vary depending on several following factors but not limited to:
  • Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming)



  • Optics
  • A set of projector-quality, high contrast aspheric lens
  • 15°-30°Smooth, precise and quiet motorized zoom
  • Smooth electronic focus



  • Framing System
  • 4-Motor driven 4-blade framing shutter system
  • Fast, smooth and quiet framing
  • Smooth, flexible blade movements at variable speed to create different shapes
  • Preset framing marocs



  • Color System
  • Sophisticated 5 colors mixed, red/green/blue/amber/lime
  • Infinte pure and even color mixing
  • 2700K-12000K color temperature adjustable
  • Preset color macros
  • Pure and even warm white (3200K)/cool white (5600K) coverage
  • Strobe Effect
  • 25T/sec high speed LED shutter/strobe effect with variable speed



  • Dimming System
  • 0-100% Smooth linear LED dimming
  • 4 Dimming curve modes, linear/square law/Inv square law/S-curve
  •
  • Preset Program
  • Auto running settings: 8
  • Sound control settings: 2



  • Control System
  • 1/14(CW/WW), 2/19(2-IN-1), 5/22(5-IN-1) DMX channels USITT DMX-512
  • RDM available (Remote Device Management)
  • DMX512, master-slave, or auto operation
  • DMX recorder and edit function integrated
  • Shielded input signal protection for stable signal without interference
  • IP rated 3-Pin XLR DMX connectors IN/OUT



  • Display System
  • 2.8" Touch TFT LCD display
  • 4 Control buttons
  • 180°Reversible for LCD display
  • Display Auto OFF



  • Cooling System
  • Advanced cooling system integrated aluminum and copper with liquid
  • Constant temperature readout and management function
  • Over temperature protection management



  • Power Supply
  • Electronic supply with active PFC
  • AC100-240V 50/60Hz
  • IP65 rated power cable IN
  • 420W/280W Power consumption
  • Housing
  • Skeleton made of aluminum and steel metal plates
  • Exterior finish: Black



  • Installation
  • Single hanging bracket
  • 1*Safety attachment point



  • Operating Condition
  • Operating positions: all
  • -25℃ to 45℃ ambient temperature
  • IP65 protection rating



  • Compliance
  • CE
  • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
  • 2014/30/EU - Electromagnetic Compatibility (EMC)
  • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)



  • Weight
  • N.W.: 16.7kg
  • G.W.: 20kg



  • Dimensions
  • Product Dimensions:301.4(D)*767.6(W)*531.2(H)mm
  • Packing Dimensions:315(D)*955(W)*330(H)mm
